infiRay Outdoor MATE MAH50 640 50mm Clip-On - DISCONTINUED

The InfiRay Outdoor MATE Series thermal clip-on brings an all-new level of versatility to your existing day scope. With a high-performance 12 μm detector, magnesium alloy housing, distortion-free display, and removable control pad, the MATE series ensures a precise and repeatable transition when day turns to night. The MATE can be mounted directly to the objective of your day scope or be attached via MIL-STD-1913 Picatinny rail. Additional accessories, including an external LRF module and monocular extension, provide improved flexibility on your next hunt or trip to the range.

Data Sheet

• Optics

  Objective Focal Length

  50mm

  Detection Range

  2400 Yards

  Objective Lens Material

  Germanium

  Optical Magnification

  1X

  Digital Magnification

  8X, stepped

  Focusing Mechanism

  Manual Focus

  Display Type

  AMOLED

• Features & Performance

  Wifi

  Yes

  Image Capture

  Yes

  Mobile App

  Yes

  Connector Output

  Power/Data

  Connector Type

  USB-C

  Video Output

  Analog RS-170/NTSC

  Onboard Recording

  Yes

  Warranty

  5 Years

• Environmental Specifications

  Recoil Rating

  1000 g/s² (300 Win./7mm Mag)

• Physical

  Mounting Interface

  Picatinny STD-1913 rail

• Sensor Specifications

  Sensor Type

  InfiRay MICRO II

  Sensor Pixel Size

  12μm

  Thermal Sensitivity

  <50mk

  Non-Uniformity Correction (NUC)

  Manual, Automatic, Semi-Automatic

  Spectral Response

  8-12 Microns

  Sensor Frame Rate

  50hz

  Device Technology

  Thermal Imaging

  Sensor Resolution

  640×512
