Description
New for 2025, the BOLT line brings Nocpix thermal performance into an affordable weapon sight platform. Available in two models, the L35 (384×288) and P25 (256×192), both optics feature an integrated laser rangefinder and ballistic calculator, providing long-range precision without breaking the budget. Built for the field, the BOLT combines an internal rechargeable battery with a removable hot-swappable 18650 auxiliary battery for extended run time. Designed to mount like a traditional day optic, it is compatible with standard 30 mm rings and mounts, making it equally at home on bolt-action and semiautomaticrifles. While not as feature-rich as the ACE series, the BOLT models deliver reliable thermal imaging, intuitive controls, and rugged construction in a streamlined package. For the first time, Nocpix offers a budget-friendly option with a built-in rangefinder, making the BOLT line a tremendous value for shooters looking to step into thermal without compromise on critical capabilities.
Product Specifications
Optics
- Display Type: AMOLED
- Display Resolution: 1024 × 768
- Eye Relief: 50 mm
- Diopter Adjustment Range: -5 to +5
- Focusing Mechanism: Manual
- Objective Lens Diameter: 25 mm
- Objective F-Number: F/1.0
- Objective Focal Length: 25 mm
- Objective Lens Material: Germanium
- Optical Magnification: 3.5×
- Digital Magnification: 4×
- Field of View (Horizontal): 7.0°
- Field of View (Vertical): 5.3°
Features & Performance
- Startup Time: <10 seconds (instant from standby)
- Integrated Rangefinder: 1,300-yard laser rangefinder
- Color Palettes: White Hot, Black Hot, Red Hot, Color, Violet, Crimson, Viridian
- Picture-in-Picture Mode: Yes
- Storage Capacity: 32 GB internal memory
- Battery Life: 6+ hours
- Power Options: USB-C external, 18650 battery, built-in battery pack
- Connector Output: Power/Data (USB-C)
- External Power Source: USB-C
- Mobile App Compatibility: Yes
- User-Updatable Firmware: Yes
- One-Shot Zero Function: Yes
- Standby Mode: Yes
- Wi-Fi Connectivity: Yes
- Onboard Recording: Yes
- Image & Video Capture: Yes
- Video Output: Yes
- Reticles: 8 options (7 static, 1 customizable)
- Country of Manufacture: China
- Warranty: 5 years
Sensor Specification
- Sensor Type: Nocpix 256 Thermal Sensor
- Resolution: 256 × 192
- Pixel Size: 12 μm
- Frame Rate: 50 Hz
- Thermal Sensitivity (NETD): ≤20 mK
- Non-Uniformity Correction (NUC): Manual, Automatic, Semi-Automatic
- Technology: Thermal Imaging
Environmental Specifications
- Operating Temperature Range: -4°F to 122°F (-20°C to 50°C)
- Recoil Rating: 1000 g/s² (up to .300 Win Mag / 7mm Mag)
- Ingress Protection: IP67 (waterproof and dustproof)
Physical
- Housing Material: T-6063 Aluminum
- Dimensions (L × W × H): 14.8” × 3.6” × 3.0”
- Weight: 30.7 oz
