Description
The AGM ObservIR LRF Thermal & Digital Day/Night Vision binocular is some of the most technologically advanced and feature-packed optics in the world. The primary engine behind these binocular lies within the main thermal viewing channel, with its high-sensitivity 12 micron detector. Unlike other thermal binoculars on the market, the ObservIR LRF also come outfitted with a digital day/night channel as well, which is great for aiding in recognition of targets detected by the thermal channel. The built-in 1,000m laser rangefinder simply takes the ObservIR LRF to another level, and this is without even mentioning its 64GB of internal memory and Wi-Fi compatibility.
The ObservIR LRF monoculars also come packed with numerous software improvements, and many features that have become commonplace within the AGM thermal product assortment: high-sensitivity thermal detector, 35 mm objective lens with a 1.0 aperture, 3840x2160 ultra-low light CMOS sensor, various viewing modes, multiple color palettes, picture-in-picture mode, built-in laser rangefinder, GPS module, long-range IR illuminator, up to 8 hours of battery life on removable, rechargeable 18650 batteries,
USB Type-C port for external power capabilities, IP67 waterproof rating. The package includes four 18650 batteries, wrist strap and charger.
Warning: California's Proposition 65
- Dual-spectrum thermal and digital day/night system
- 12μm high-sensitivity thermal sensor
- 384x288 thermal resolution
- 4x – 20x thermal magnification
- Digital image processing technology
- Ultra-low illumination optical channel
- 3840×2160 optical resolution
- Built-in IR illuminator
- Eye-safe 1,000 m laser rangefinder
- 1920×1080 resolution, 0.49-inch OLED display
- Digital Magnetic Compass
- Built-in GPS module
- Video/audio recording and snapshot capture
- Built-in 64 GB EMMC storage
- Wi-Fi hotspot
- Standby mode
- 8-hour continuous operation on a single charge
- Auto screen-off function to saving energy
- External power supply capability
- Rugged housing with rubber overmolding
- Waterproof and dustproof
Specifications
- Interpupillary Distance - 60 mm to 74 mm
- Safety Class for Laser - Class 1
- Palettes - Black Hot, White Hot, Red Hot, Fusion
- Dimensions - 221×142×71 mm (8.7×5.6×2.8 in)
- Infrared Illuminator - Built-in 850nm Smart IR. Power and beam angle adjustment.
- Distance Measurement - Laser Rangefinder: up to 1,000 m, ±1 m accuracy
- Scene Mode - Jungle, Recognition
- Video Recording - Yes
- Audio Recording - Yes
- Magnification - Thermal Channel - 4.0x – 20x / Optical Channel - 5.5x – 22x
- Detector type - Thermal Detector - 12μm VOx Uncooled Focal Plane Array / Digital Sensor - 3840×2160, 1/88” Progressive Scan CMOS
- FFC (Flat Field Correction) - Auto, Manual, External Correction
- Highest Temperature Spot Tracking -Yes
- Standby Mode - Yes
- Refresh rate - 50 Hz
- Resolution - 384 × 288
- Laser Wavelength - 905 nm
- Detection Range (6' object) - 1,800 m
- Snapshot - Yes
- Lens system - Thermal Channel - 35 mm; F1.0 / Optical Channel - 60 mm, F2.2
- NETD - Less than 15 mK (25°C, F#=1.0)
- Field of view (H × X) - Thermal Channel - 7.5° × 5.7° / Optical Channel - 6.9° × 4.1°
- Diopter adjustment range - -5 to +3
- Monitor - 1920×1080, 0.49 inch, OLED, 50 FPS
- Display - Day, Night, Auto
- Storage - 64 GB EMMC
- Battery Type - Two 18650 rechargeable battery (removable)
- Wi-Fi - Yes
- Battery Life (Operating) - Up to 8 hours continuous running (@25°C, WiFi, IR and LRF off)
- Power supply - 5 VDC/2 A, USB Type-C interface. Supports external power supply.
- Operating Temperature Range - -20°C to 55°C (-4°F to 131°F)
- Weight - 0.91 kg (2.01 Ib)
- Protection Level - IP67 (Waterproof)
